8-channel real-time network DVR Security System

8-channel real-time network DVR with 8 Sharp 6mm Lens 30LED Infrared Night Vision security cameras and Seagate 500 GB Hard Drive, this security system is the most advanced SOC technology and supports standard H.264 encoding. so the image quality is higher, network transmission effect are better and the system is more stable. This system is suitable for monitoring places such as shops, supermarket, homes, schools or hotels. ideal for outdoor use.

Whats Included

1 x 8-channel real-time network DVR
8 x 1/4 inch Sharp Chip, 420TV Lines night vision security Cameras
1 x 500 GB Hard Drive
8 x 50' Heavy Duty Coaxial Plug and Play Camera Lead
2 x AC/DC power Adapter
1 x Remote control

Features

• Night vision distance 20 meters
• 16-bit true-color semi-transparent graphical menu interface
• variety of recording modes: manual, timing, movement and alarm recording
• USB 2.0 for data backup
• USB 1.1 for the mouse operation
• Dual stream technology
• Support network to implement multi-screen real-time browsing, parameter setting, copy or playback
• Support phone monitoring
• Support event classification and precise time search and playback
• Defaulted parameter value fast recovery
• Easy to install

Standalone real-time network Specs

Video compression format: Main profile H.264
Main profile H.264: BNC 8-channel input/2-channel output
VGA output : support (optional)
Audio compression method : 8kHz 16bit ADPCM
Audio input/output: RCA 1-channel input, 1-channel output.
Alarm type : Motion detection, sensor trigger, video loss, disk full, disk error
Alarm input/output: 8-channel alarm input /1-channel alarm output
Display : 1/4/8-channel switchable
Display resolution: PAL: D1 (704 576) NTSC: D1 (720 480)
Display frame rate: Single-channel PAL: 25fps, NTSC: 30fps
Playback Resolution : PAL CIF(352288) NTSC CIF(360240)
Recording Total frame rate: PAL 200fps@CIF NTSC 240fpsCIF
Recording mode: Start automatic continuous, timing video, motion detection, trigger alarm.
Video packing time: 15/30/45/60 minutes adjustable
Hard-disk: Support one SATA hard-disk drive (maximum capacity is 1T)
Network protocol: Support DHCP, UDP, TCP/IP, DNS, DDNS, PPPOE and other protocols.
Network functionality: Support IE browsing, real-time network monitor and network DVR parameter setting.
USB1.0 interface: Support mouse operation
USB2.0 interface: Support mobile harddisk and USB disk backup and upgrade
Playback mode: Normal playback, fast forward playback, fast backward playback, manual single-frame slow motion.
Network interface: One RJ45 10M/100M self-adaptive Ethernet port
PTZ control: Built-in RS-485 interface, support Pelco-D and Pelco-P protocol
Backup function: support USB disk backup, mobile harddisk backup, USB burner backup and network backup
Power adapter: DC 19V/2.1A
Power consumption: 15 ~ 20W (excluding harddisk)
Operating temperature: 0?+50?
Operating humidity: 10%90%

Security Camera Specs

Image Sensor: 1/4 inch Sharp CCD Chip
Validity Pixel: PAL: 512X582 NTSC: 512X492
TV System: PAL/NTSC
Horizontal Resolution: 420TV Lines
Minimum Illumination: 0.0Lux
LED: 30pcs LEDs
Infrared Distance: 20m Infrared Distance
SNR: >48dB
Gamma Correction: >0.45
White Balance: AUTO
Electronic Shutter: 1/50(1/60)-1/100,1000 sec
Backlight Compensation:: AUTO
Power Consumption: DC12V/500mA
Video Output: 1.0vp-p,75ohm VBS
Operation Temperature: -10?~+50?
Operation Humidity: 0%-96%
